Product Code: E3-32AI20M-1

Optimize your automation systems with the Red Lion IFMA Series Frequency to Analog Converter. Designed for versatility, this DC-powered converter handles a full-scale frequency range from 1 Hz to 25 KHz and offers four distinct output operating ranges. Its programmable input circuit adapts to your specific needs, while the robust power input accepts 85 to 250 VAC. Enhance system reliability with features like low-frequency cut-out and overrange indication. Benefit from added safety through its 3-way electrical isolation between power, input, and output. Ideal for integration into IO Systems within the automation industry, this converter ensures precision and durability in demanding environments.

Maximum Temperature (°C)	50
Minimum Temperature (°C)	0
Brand	RED LION
Series	IFMA
Type	High Density
Mounting Type	DIN Rail
Operational Temperature Range (°C)	-40 to +75
Communication	RS-485
Communication Protocols	MODBUS, ASCII
No. of Analogue Inputs	32
No. of Ethernet Ports	2
No. of IO	32
No. of Serial Ports	1
Rated Current (mA)	355
Rated Maximum Operational Voltage AC (V)	250
Rated Minimum Operational Voltage AC (V)	85
Rated Operational Voltage DC (V)	12 - 24
Dimensions (mm)	142.2W x 134H x 72.4D
Weight (g)	1300

Programmable Logic Controllers & I/O

RED LION E3 I/O MODULE-32 20MA ANALOG INPUTS E3-32AI20M-1
