IPD FUSE LINK 25A 440VAC OFF-SET TAG MOTOR RATED 44.5mm FIXING 80kA A1, 401228 NIT20M25
Zoom
Zoom
IPD FUSE LINK 25A 440VAC OFF-SET TAG MOTOR RATED 44.5mm FIXING 80kA A1, 401228 NIT20M25
Product Code: NIT20M25
The NIT offset bolted tags-2hole fixing BS fuse links, available in sizes A1 to A4, are designed for general industrial applications. They comply with the standard BS88-2 and IEC 60269-2. These fuse links have a breaking range and utilisation category of gM, providing good peak and let-through current limitation. The breaking capacity is AC: ASTA 20 certified to 80 kA. They have a rated current of 25A and can handle voltages of 440VAC/250VDC.
Technical Specifications
Brand
IPD
Body Diameter (mm)
14.1
Breaking Capacity AC (kA)
80
Breaking Capacity DC (kA)
40
Fixing Centres (mm)
44.5
Fuse Shape
Offset slotted bolted tags
Fuse Type
BS88/A1
Insulated Metal Gripping Lugs
No
Maximum Ambient Temperature (°C)
40
Pack Quantity
10
Rated Current (A)
25
Rated Voltage AC (V)
440
Rated Voltage DC (V)
250
Standards
BS 88-2, AS 60269, IEC 269-2-1, ASTA20
Suitable Fuse Holder
RS20 & RSM32
Utilisation Category
gM
Voltage Type
AC/DC
