PANASONIC PROGRAMMABLE CONTROLLER 24V DC 14 POINTS RS-232C AFP0RC14CRS

The Programmable Controller is designed for 24 V DC power supply and has a total of 14 controllable I/O points. It consists of 8 input points and 6 relay output points. The programming method used is Relay symbol with cyclic operation control. The controller is equipped with one RS-232C port for communication. It operates within an input voltage range of 21.6 to 26.4 V DC. The output type of the controller is 1a, with 4 points per common and an additional point per common, totaling to 6 points per common. The rated control capacity of the controller is 2 A at 250 VAC and 2 A at 30 VDC, with a maximum current of 4.5A per common.
