ABB RCBO 6kA 1P+N 32A C CURVE TYPE A 30mA 1 MODULE DSN201EC32A30

Product Code: DSN201EC32A30

Residual current circuit breakers with overcurrent protection, 1P+N 240 V AC. Rated current 32A, rated residual current 30 mA. Type A, C curve, breaking capacity 6 kA, rated impulse withstand voltage 6 kV, maximum surge current 2.5 kA. One module wide. The neutral is switched. Suitable for residential, commercial, and industrial applications. Degree of protection IP20.

Technical Specifications

Brand ABB
Series DSN201E
Ambient Temperature Range (°C) -25 to 40
Mounting Type DIN Rail
AC Voltage (V) 240/415
Current Rating (A) 32
Curve Type C
Family DSN201E
Icn-Rated Short Circuit Capacity (kA) 32
Impulse Withstand Voltage (kV/1.2µS) 6
No. of Poles 1P+N
Rated Current (A) 32
Rated Frequency (Hz) 50/60
Rated Impulse Withstand Voltage (kV) 6
Rated Operational Voltage AC (V) 240
Rated Residual Current (mA) 30
Rated Short-Circuit Capacity - Icn (kA) 32
Residual Current Type A
Dimensions (mm) 86H × 70D × 17.8W
Trip Curve C Curve
No. of Modules 1
Type of Residual Current A
Degree of Protection Housing - IP40, Terminals - IP20
Standards and Approvals IEC/EN 61009-1,IEC 61009-2-2, AS/NZS 61009.1
Poles 1P+N
