Product Code: EP-225F

Optimize your automation systems with the Emerson RSTi-EP Digital Output Module. This compact, DIN rail-mounted PLC from the RSTi-EP series is designed for distributed slice applications and offers a high channel density of 4 to 16 points. It supports both positive and negative logic and has an output rating of 0.5 to 6A at 24VDC, accommodating 1,2,3, or 4 wire connections. With dual RJ45 ports, it ensures network redundancy and seamless integration with PROFINET RT, PROFIBUS, Modbus TCP, and EtherCAT protocols. Ideal for machine control, light process control, and general automation tasks€”this module delivers reliable performance in a variety of settings.

Communication Protocols	MODBUS, PROFINET, PROFIBUS, EtherCAT, EtherNet/IP
Current Consumption	8mA; 25mA + Loads, 20.4-28.8V DC
Brand	Emerson
Degree of Protection	IP20
Maximum Nominal Output Voltage DC (V)	24
Maximum Temperature (°C)	60
Minimum Temperature (°C)	-20
Mounting Type	DIN Rail
No. of Digital Outputs	16
No. of Ethernet Ports	2
No. of IO	16
No. of Output Points	16
Nominal Output Current (A)	0.5
Rated Maximum Operational Voltage DC (V)	28.8
Rated Minimum Operational Voltage DC (V)	20.4
Redundancy	PNSR
Series	RSTi-EP
Standards and Approvals	ATEX/IECeX

Programmable Logic Controllers & I/O

EMERSON RSTI-EP DIGITAL OUTPUT, 16 POINTS, POSITIVE LOGIC, 24VDC, 0.5A, RSTI-EP 1 WIRE EP-225F
