Novaris SD3-150-275 Surge Diverter 19kA 3 PH 150kA 230VAC Mount Aluminium IP20

Product Code: SD3-150-275

  • Rated for 230 VAC, 150 kA (L-N) current
  • Digital display for easy monitoring
  • IP20 protection and panel mounting
  • Aluminium build, compact 200x80x200 mm
  • Fast response time of <25 ns (L-N)
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Lightning Impulse Current (10/350 &#181;s) - Iimp (kA) 19 (L-N)
Maximum Continuous Operating Voltage MCOV AC (V) 275 (L-N)
Maximum Discharge Current (8/20µs) - Imax (kA) 150 (L-N)
No. of Poles 3P+N PE
Nominal Discharge Current (8/20µs) - In (kA) 60 (L-N)
No. of Phases 3
Nominal Voltage AC (V) 230
Operational Temperature Range (&#176;C) -40 to 70
Voltage Protection Level - Up (kV) <1.6 (L-N)
Weight (kg) 1.8
Dimensions (mm) 200W x 80H x 200L
Product Type Surge Diverter
Brand NOVARIS
Series SD3
Connection Type Shunt
Contact Configuration SPDT
Degree of Protection IP20
Depth 200 mm
Display Type Digital
Fuse Rating 80 A
Height 80 mm
Humidity 5-95%
Lightning Impulse Current 19 kA (L-N)
Material Aluminium
Modes of Protection L-L, L-N
Mounting Type Panel
Number of Ports 1
Operational Temperature -40 to 70 deg C
Phase 3
Rated Current 150 kA (L-N)
Rated Short Circuit Current 50 kA
Rated Voltage 230 VAC
Response Time <25 ns (L-N)
Standards and Approvals IEC 61643-11:2011, AS/NZS 1768:2007, UL 1449 3rd Edition, IEEE 62.41.2:2002
Tightening Torque 0.5 N-m, 2 N-m
Voltage Protection Level <750 V
Weight 2.8 kg
Width 200 mm

Description

The MULTIMOV surge diverter is a 3 phase 3P+N PE device designed to protect your main switchboard (MSB) from power surges. It has a nominal voltage of 230 VAC and a maximum continuous voltage of 275 VAC. The surge diverter can handle a maximum discharge current of 150 kA (L-N) in an 8/20ms time frame, and an impulse current of 19 kA (L-N) at 10/350ms. Its nominal discharge current is 60kA (L-N) at 8/20 ms. With a voltage protection level of less than 1600V (L-N) at the nominal discharge current, this surge diverter provides reliable protection for your network. It is suitable for use with a TN-C-S (MEN) network type main switchboard. The MULTIMOV surge diverter offers all mode protection and features a shunt connection. It also includes a percentage active display and a failsafe alarm contact, allowing for remote monitoring. Protect your main switchboard with the reliable and efficient MULTIMOV surge diverter.
