IDECYW4L-MF2E20QM3G Illuminated Pushbutton 22mm Extended w/Full Shroud Momentary Green 230/240VAC/DC 2NO

Product Code: YW4L-MF2E20QM3G

  • Illuminated pushbutton with green LED
  • Durable metal bezel for robust use
  • IP65 front protection against dust and water
  • 5 million operations mechanical life (single contact)
  • Operates in temperatures from -20 to 55°C
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 30W x 41.4H x 64.8D
Operating Voltage DC (V) 230/240
Operating Voltage AC (V) 230/240
No. of Normally-open Contacts 2
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Extended with Full Shroud
Bezel Material Metal
Colour Green
Contact Configuration 2NO
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Green
Lamp Type Built-in LED
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model Extended With Full Shroud Momentary- With LED Lamp
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Rated Voltage 230/240 VAC/DC
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW4L-MF2E20QM3G is a 22mm illuminated pushbutton with momentary action, designed for 230/240V applications. This compact and lightweight unit features space-saving, 10mm thick contact blocks and a removable operator for flexibility. It comes with a durable metal bezel and offers unibody pilot lights and key selector switches. The separate contact block design simplifies installation and maintenance procedures.
