IDECHW1B-M1F01R-K Non-Illuminated Pushbutton 22mm Flush Momentary Red 1NC

Product Code: HW1B-M1F01R-K

  • Non-illuminated, flush red pushbutton
  • IP65 front protection for durability
  • Screw terminal with 1NC contact config
  • Rated insulation voltage of 600V
  • Round plastic bezel in black
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NC
Insulation Resistance (MO) 100
Operational Temperature Range (°C) -25 to + 60
Rated Continuous Current (A) Contact Rating - 10
Pollution Degree 3
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Rated Impulse Withstand Voltage (kV) 4
Mounting Hole Diameter (mm) 22
Tightening Torque (Nm) Locking Ring - 2.0
Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Button Colour Red
Colour Red
Contact Configuration 1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Mode of Operation Momentary
Operational Temperature -25 to 60 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Terminal Type Screw

Description

The IDEC HW1B-M1F01R-K is a robust Non-Illuminated Pushbutton featuring an extended momentary function and a single 1NC finger-safe terminal. Designed in red for clear visibility, this pushbutton ensures secure operation with its tamperproof construction. Ideal for various industrial applications, it offers reliable performance and enhanced safety.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
