IDECHW1B-M1F10-B Non-Illuminated Pushbutton 22mm Flush Momentary Black 1NO

Product Code: HW1B-M1F10-B

  • Non-illuminated, flush actuator design
  • IP65 front protection for durability
  • Screw terminals for secure connection
  • 22 mm diameter with round plastic bezel
  • Momentary function with silver contacts
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 1
Terminal Shape Screw terminal
Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Button Colour Black
Colour Black
Contact Configuration 1NO
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Operational Temperature -25 to 60 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Terminal Type Screw

Description

The IDEC HW1B-M1F10-B is a 22mm black pushbutton designed for reliable and responsive operation. This momentary switch features both flush and extended sub-components, allowing for versatile application. It is constructed with a durable plastic bezel, ensuring longevity and resilience in various industrial environments. Ideal for control panels and machinery interfaces, this pushbutton offers a straightforward solution for user input commands.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
