IDECHW1B-M2F11-R Non-Illuminated Pushbutton 22mm Extended Momentary Red 1NO+1NC

Product Code: HW1B-M2F11-R

  • Non-illuminated, extended actuator design
  • IP65 front protection, IP20 terminal rating
  • 1NO+1NC contact configuration with silver contacts
  • Rated for 600 V insulation and 10 A current
  • Fits standard 22 mm cutout size
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 1
No. of Normally-closed Contacts 1
Terminal Shape Screw terminal
Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Extended
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Button Colour Red
Colour Red
Contact Configuration 1NO+1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Operational Temperature -25 to 60 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Terminal Type Screw

Description

The IDEC HW1B-M2F11-R is a 22mm red pushbutton designed for easy and reliable operation. This momentary switch features an extended actuator for quick access and a durable plastic bezel. Ideal for various industrial applications, it ensures efficient control within your system.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
