IDECYW1B-M4E10G Non-Illuminated Pushbutton 40mm Mushroom Momentary Green 1NO

Product Code: YW1B-M4E10G

  • Non-illuminated mushroom actuator
  • IP65 front protection, IP20 terminal
  • 5 million ops single block life
  • Screw terminal connection
  • CE, cULus, UKCA, CCC certified
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO
Conventional Free-Air Thermal Current - Ith (A) Contact Rating - 10
Insulation Resistance (MO) 100
Mushroom Diameter (mm) 40
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Mushroom
Bezel Material Plastic
Bezel Type Plastic
Button Colour Green
Colour Green
Contact Configuration 1NO
Contact Material Silver
Cutout Size 40 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 66.3 mm
Diameter 40 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Mode of Operation Momentary
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Terminal Type Screw
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW1B-M4E10G is a robust Non-Illuminated Mushroom Pushbutton featuring a green, 40mm diameter momentary switch. It comes with a single Normally Open (1NO) contact and is suitable for 22mm mounting. This pushbutton ensures safe operation with an IP20 protection rating.
