IDEC FC6A-J4CN1 Analog Input Module 0-10VDC 4 Digital Inputs 10-Pin

Product Code: FC6A-J4CN1

  • 0-10 VDC input for versatile applications
  • Handles 0-20 mA & 4-20 mA current ranges
  • Secure screw terminal connections
  • IP20 protection against solid objects
  • CE, TUV, UL certified for safety and quality
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Analogue Signal - Current (mA) 0-20, 4-20
Analogue Signal - Voltage (V) 0 to 10, -10 to +10
No. of Input Points 4
Terminal Pitch (mm) 3.81
Terminal Pin 10
Product Type Analog Input Module
Brand IDEC
Series FC6A
Connector Type Screw fastened
Degree of Protection IP20
Number of Analogue Inputs 4
Number of Digital Inputs 4
Number of Pins 10
Rated Current 0-20 mA, 4-20 mA
Rated Voltage 0-10 VDC
Standards and Approvals CE , Class I Div 2 Hazardous Location, TUV, UL Certification
Terminal Type Screw
Warranty 36 Months

Description

The IDEC FC6A-J4CN1 is a 4-point universal analog input module designed for flexible and precise data acquisition. It seamlessly integrates with automation systems, providing reliable performance in various industrial applications.
