Specifications

Dimensions (mm)	251W x 726H x 357D
Size of Frame	R6
Rated Supply Voltage AC (V)	380 - 415
Weight (kg)	42.2
Output Current - Normal Duty (A)	105
Output Power - Normal Duty (kW)	55
Output Power - Heavy Duty (kW)	45
Output Current - Heavy Duty (A)	87
Product Type	Industrial Drive With B'CP
Brand	ABB
Series	ACS880
Ambient Temperature	-15 to 40 deg C
Degree of Protection	IP21
Depth	357 mm
Frame Size	R6
Height	726 mm
Mounting Type	Wall
Number of Analogue Inputs	2
Phase	3
Rated Current	105 A
Rated Power	45 kW
Rated Voltage	380-415 VAC
Standards and Approvals	CE/ EN 61800-5-1:2007/ EMC/ ATEX/ RoHS 2011/65/EU/ TÜV/ UL 508C/ CSA
Width	251 mm
