ABB ATB2403E ALUMINIUM TERMINAL BLOCK EARTH 6 CONNECTIONS CABLE 240mm²

Product Code: ATB2403E

The Aluminium Terminal Block is designed for earth connections and has 6 connections. It can accommodate cable sizes up to 240mm² and comes in a yellow/green colour. The nominal current for copper cables is 425A and for aluminium cables is 380A, with a nominal insulation voltage of 600V. This terminal block is suitable for use with both copper and aluminium cables. The tin plating on the block prevents galvanic reactions. It features an internal barrier that allows for the connection of both aluminium and copper cables to a single block. The screw head size is 8mm, making it easy to mount on panels.

Technical Specifications

Brand ABB
Colour Yellow/Green
Maximum Cable Cross Section (mm²) 240
No. of Connections 6
Nominal Current (A) 425 (Cu)/380 (AL)
Nominal Insulation Voltage (V) 600
Screw Head Size (mm) 8
Tightening Torque (Nm) 12 (35-70mm²)/45 (95-240mm²)
