Specifications

Dimensions (mm)	10W x 13H x 4D
Suitable For	Earthing
Weight (kg)	0.4
Reference No.	772313
Type	Short-Circuiting Devices
Wire Cross Section (mm²)	16
Maximum Output Short-circuit Current (A)	33.5k (0.5s)
Product Type	Ball Head Cap
Brand	DEHN
Connection Type	20 mm Fixed Ball Point
Cross Section	16-120 sq-mm
Depth	4 mm
Height	13 mm
Material	Copper Alloy
Operational Temperature	-25 to 55 deg C
Rated Current	33500 A
Standards and Approvals	EN/IEC 61230 (DIN VDE 0683-100)
Suitable For Use With	25 to 120 sq-mm Cables
Weight	0.4 kg
Width	10 mm
