Specifications

Dimensions (mm)	27W x 90H x 65D
Suitable For	Pluggable DIN Rail Mounted
Voltage Protection Level - Up (kV)	240
Weight (kg)	0.099
Nominal Load Current AC - I? (A)	0.2
Enclosure Material	Thermoplastic, UL 94 V-0
Nominal Voltage (V)	130
Mounting Method	DIN rail (top hat rail) 35 mm
Earth Fault Protection	Separate conductor
Maximum Continuous Voltage DC (V)	170
Voltage Protection Level Earth	600
Limiting Frequency (Hz)	17
Voltage Protection Level - Up (V)	Line-Line for In C2: ≤ 275 Line-PG for In C2: ≤ 600 Line-Line at 1 kV/µs C3 ≤ 240 Line-PG at 1 kV/µs C3 ≤ 600
L-PE Capacitance (pF)	≤ 15
L-L Capacitance (pF)	≤ 300
Nominal Voltage DC (V)	130
Nominal Discharge Current (8/20µs) - In (kA)	5
Operational Temperature Range (°C)	-40 to 80
Reference No.	918411
SPD Type	2
Lightning Impulse Current (10/350 µs) - Iimp (kA)	1
Maximum Continuous Operating Voltage MCOV DC (V)	170
Product Type	Surge Arrester
Brand	DEHN
Capacitance	<=300 pF (L-L), <=15 pF (Line-PG)
Colour	Yellow
Connection Type	RJ45 Terminal
Cross Section	0.08-2.5 sq-mm Solid, 0.08-2.5 sq-mm Flexible
Degree of Protection	IP10
Depth	65 mm
Height	90 mm
Lightning Impulse Current	1 kA
Material	Thermoplastic
Mounting Type	35 mm DIN Rail
Operational Temperature	-40 to 80 deg C
Rated Current	2.5 kA (Per Line), 5 kA (Total)
Rated Voltage	170 VDC
SPD Class	Type 2
Standards and Approvals	IEC 61643-21, EN 61643-21
Voltage Protection Level	<=275V (L-L) for In C2), <=600V (Line-PG) for In C2), <=240V (L-L) at 1 kV/µs C3), <=600V (Line-PG) at 1 kV/µs C3)
Weight	99 g
Width	27 mm
