DEHN 274230 Conductor Holder With Wood Screw 5x50mm 8x40mm Screw Clamp Mount 4mm D 9mm H M8 Plastic

Product Code: 274230

  • Designed for 6 mm dia round conductors
  • Durable plastic construction
  • Screw clamp mounting for secure fit
  • Complies with EN 62561-4 standards
  • Lightweight at 0.045 kg
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 5W x 9H x 4D
Suitable For Diameter round conductor 6mm
Weight (kg) 0.045
Mounting Method With plug
Rod Diameter (mm) 6 - 10
Holder Material Stainless steel 304 (V2A)
Saddle Material Stainless steel 304 (V2A)
Carrier Material Stainless steel 304 (V2A)
Fixing Screw Type Screw - 5 x 50 mm, Plastic Plug - Ø8 x 40 mm
Product Type Conductor Holder With Wood Screw
Brand DEHN
Base Material Plastic
Connection Type 5 x 50 mm, 8 x 40 mm Plastic Dowel
Depth 4 mm
Height 9 mm
Material Plastic
Mounting Type Screw Clamp
Standards and Approvals EN 62561-4
Suitable For Use With 6 mm Dia Round Conductor
Thread Size M8
Weight 0.045 kg
Width 5 mm
