DEHN 423010 Downpipe Clamp 60-100mm 10.5mm M8 x 25mm Screw Steel

Product Code: 423010

  • M8 x 25 mm screw connection
  • Fits earthing rods securely
  • Hot dip galvanized steel finish
  • Clamping range of 60-100 mm
  • Handles lightning currents up to 100 kA
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 337W
Suitable For Earthing
Weight (kg) 0.113
Class (Lightning Current Carrying Capability) (kA) 100
Length (mm) 337
Reference No. 423010
Fixing Hole Ø (mm) 10.5
Type Equipotential Bonding
Clamping Range (mm) 60 - 100
Surface Protection Hot-dip Galvanized
Clamping Range Rd/Rd (mm) 60 - 100
Product Type Downpipe Clamp
Brand DEHN
Clamping Range 60-100 mm
Connection Type M8 x 25 mm Screw
Finish Hot Dip Galvanized
Length 337 mm
Lightning Current Carrying Capability 100 kA
Material Steel
Screw Size M8 x 25mm
Size 10.5 mm
Standards and Approvals EN 62561-1, IEC 62305
Suitable For Use With Earthing Rods
Weight 0.113 kg
Width 337 mm

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
