Specifications

Air Flow (m³/h)	660/745
Operational Temperature Range (°C)	-10 to +55
Rated Current (A)	0.50/0.72
Rated Frequency (Hz)	50/60
Rated Power (W)	111/140
Rated Voltage AC (V)	230
Dimensions (mm)	325H x 325W x 115D
Noise Level (dBA)	72.8/75.8
Product Type	Fan Filter
Brand	FANDIS
Air Flow	660 cu-m/h, 745 cu-m/h
Colour	Light Grey RAL 7035
Degree of Protection	IP54
Depth	115 mm
Height	325 mm
Housing Material	ABS/PC Alloy
Material	Synthetic Fiber
Noise Level	72 dBA, 75 dBA
Operational Temperature	-10 to 55 deg C
Rated Current	0.5 A, 0.72 A
Rated Frequency	50/60 Hz
Rated Power	111 W, 140 W
Rated Voltage	230 VAC, 24-250 VDC
Standards and Approvals	CE, UKCA
Width	325 mm
Wire Cross Section	20-14 AWG
