IDEC YW1P-1EQM3R Flush Pilot Light Red 230/240VDC 22mm Dia Mount Hole

Product Code: YW1P-1EQM3R

  • Pilot light with 1NO+1NC contact config
  • Maintained actuation for reliable operation
  • Positions A and C maintained
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 29.6W x 24H x 55.7D
Operating Voltage DC (V) 230/240
Operating Voltage AC (V) 230/240
Product Type Flush Pilot Light
Brand IDEC
Actuation Type Maintained
Colour Red
Contact Configuration 1NO+1NC
Degree of Protection IP65
Maintained Position A, C
Model Flush Full Voltage - With LED Lamp
Number of Positions 2

Description

The IDEC YW1P-1EQM3R Flush Pilot Light is a compact, space-efficient signaling device designed for 230/240V AC/DC systems. It features a slim 10mm contact block and a removable operator for easy maintenance. The metal bezel enhances durability, while the unibody design ensures a sleek appearance. Installation and removal are simplified thanks to the separate contact block. Additionally, the pilot light's large lens offers an expansive viewing angle for clear visibility.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
