Specifications

Dimensions (mm)	75W x 75H x 3D
Reference No.	338001
Suitable For	Diameter round conductor 7mm
Weight (kg)	0.068
Class (Lightning Current Carrying Capability) (kA)	50/100
Clamping Range (mm)	130
Surface Protection	Untreated
Rod Diameter (mm)	7 - 10
Clamping Range Rd/Rd (mm)	7 - 10
Product Type	Gutter Clamp With Twin Screw Cleat
Brand	DEHN
Clamping Range	7-10 mm
Connection Type	M6 x 16 mm Screw
Connector Type	Gutter Clamp
Depth	3 mm
Finish	Untreated
Height	75 mm
Lid Screw Type	Hexagon Screw
Lightning Current Carrying Capability	50 kA, 100 kA
Material	Aluminium
Screw Size	M6 x 16mm
Standards and Approvals	EN 62561-1
Suitable For Use With	7 mm Dia Round Conductor
Weight	0.068 kg
Width	75 mm
