Novaris HSG1-100-480 Hybrid Spark Gap Arrester 100kA 1 PH 250kA 230V 50Hz TS35 DIN Mount 200mm H Metal IP20

Product Code: HSG1-100-480

  • Rated for 230 V, 250 kA, single-phase systems
  • LED display for easy status monitoring
  • Robust IP20 protection for reliable use
  • Compact design: 60x200x70 mm dimensions
  • Fast response time of less than 100 ns
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 108W x 141H x 69D
No. of Phases 1
Operational Temperature Range (°C) -40 to 70
Product Type Hybrid Spark Gap Arrester
Brand NOVARIS
Connection Type Shunt
Contact Configuration SPDT
Degree of Protection IP20
Depth 70 mm
Display Type LED
Fuse Rating 125 A
Height 200 mm
Humidity 5-95%
Lightning Impulse Current 100 kA
Material Metal
Modes of Protection L-N
Mounting Type Panel, TS35 DIN
Operational Temperature -40 to 70 deg C
Phase 1
Rated Current 250 kA
Rated Frequency 50 Hz
Rated Voltage 230 V
Response Time <100 ns
Standards and Approvals EC 61643-11 Class I, AS/NZS 1768 Category C, IEEE C62.41 Category C, IEC 1000-4-5, UL1449 Fourth Edition
Weight 1.2 kg
Width 60 mm
