Novaris HSG1-25-480 Hybrid Spark Gap Arrester 25kA 1 PH 250kA 230V 50Hz TS35 DIN Mount 200mm H Metal IP20

Product Code: HSG1-25-480

  • Rated for 230 V, 250 kA with 1-phase protection
  • LED display for clear status indication
  • Shunt connection; SPDT contact config.
  • Complies with IEC, AS/NZS, IEEE standards
  • Fast response time of <100 ns
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Nominal Discharge Current (8/20µs) - In (kA) 100
No. of Phases 1
Nominal Voltage AC (V) 230
Operational Temperature Range (&#176;C) -40 to 70
Voltage Protection Level - Up (kV) 2.2
Response Time (ns) 100
Backup fuse rating (A) 125
Dimensions (mm) 53W x 141H x 69D
Weight (g) 53
Maximum Continuous Voltage AC (V) 480
Maximum Discharge Current (8/20µs) (kA) 200
Short Circuit Withstand Level (kA) 25
No. of Ports 1
Product Type Hybrid Spark Gap Arrester
Brand NOVARIS
Connection Type Shunt
Contact Configuration SPDT
Degree of Protection IP20
Depth 70 mm
Display Type LED
Fuse Rating 125 A
Height 200 mm
Humidity 5-95%
Lightning Impulse Current 25 kA
Material Metal
Modes of Protection L-N
Mounting Type Panel, TS35 DIN
Operational Temperature -40 to 70 deg C
Phase 1
Rated Current 250 kA
Rated Frequency 50 Hz
Rated Voltage 230 V
Response Time <100 ns
Standards and Approvals EC 61643-11 Class I, AS/NZS 1768 Category C, IEEE C62.41 Category C, IEC 1000-4-5, UL1449 Fourth Edition
Weight 1.2 kg
Width 60 mm
