IDECYW1L-MF2E11Q4S Illuminated Pushbutton 22mm Extended w/Full Shroud Momentary Blue 24VAC/DC 1NO+1NC

Product Code: YW1L-MF2E11Q4S

  • Illuminated pushbutton with built-in blue LED
  • Extended actuator with full shroud
  • IP65 front protection for durability
  • 1NO+1NC contact configuration
  • Rated for 24 VAC/DC operations
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO+1NC
Conventional Free-Air Thermal Current - Ith (A) Contact Rating - 10
Insulation Resistance (MO) 100
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Rated Voltage AC/DC (V) 24
Mounting Hole Diameter (mm) 22
Lamp Included
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Extended with Full Shroud
Bezel Material Plastic
Bezel Type Plastic
Contact Configuration 1NO+1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Blue
Lamp Type Built-in LED
LED Colour Blue
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Mode of Operation Momentary
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Rated Voltage 24 VAC/DC
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Terminal Type Screw
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW1L-MF2E11Q4S is a 22mm illuminated pushbutton featuring a blue LED for clear visibility. It includes an extended shroud for enhanced protection and operates with momentary action. The unit offers a contact configuration of 1 Normally Open (NO) and 1 Normally Closed (NC), suitable for use with both 24VAC and 24VDC power sources. Designed for easy installation with its 22mm mounting style, it also provides an IP20 rating to ensure finger safety.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
