IDECYW1L-MF2E11QHG Illuminated Pushbutton 22mm Extended w/Full Shroud Momentary Green 110VAC/DC 1NO+1NC

Product Code: YW1L-MF2E11QHG

  • Illuminated green LED for clear visibility
  • IP65 front protection against dust and water
  • Durable with 5M operations (single contact block)
  • Extended actuator with full shroud design
  • cULus, CE, UKCA, CCC certified for safety
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 30W x 41.4H x 64.8D
Operating Voltage DC (V) 110
Operating Voltage AC (V) 110
No. of Normally-open Contacts 1
No. of Normally-closed Contacts 1
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Extended with Full Shroud
Bezel Material Plastic
Colour Green
Contact Configuration 1NO+1NC
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Green
Lamp Type Built-in LED
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model Extended With Full Shroud Momentary- With LED Lamp
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Rated Voltage 110 VAC/DC
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Terminal Type Screw
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW1L-MF2E11QHG is a green LED illuminated pushbutton designed for efficient operation in industrial environments. This momentary switch features 1 Normally Open (NO) and 1 Normally Closed (NC) contact, with a shroud for added safety. Its compact design includes space-saving 10mm thick contact blocks and a metal bezel for durability. The removable operator and separate contact block ensure easy installation and maintenance. Ideal for use in control panels, this 22mm switch from the YW series enhances functionality while saving space.
