IDECHW1L-M2F11A-K Illuminated Pushbutton Kit 22mm Extended Momentary Amber 1NO+1NC

Product Code: HW1L-M2F11A-K

  • Illuminated pushbutton with amber colour
  • IP65 front protection for reliable use
  • 5 million operations mechanical life
  • 1NO+1NC contact configuration
  • Operates in -25 to 60°C range
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO+1NC
Operational Temperature Range (°C) -25 to +50
Rated Continuous Current (A) Contact Rating - 10
Pollution Degree 3
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Rated Impulse Withstand Voltage (kV) 2.5
Insulation Resistance (MO) 100
Mounting Hole Diameter (mm) 22
Tightening Torque (Nm) Locking Ring - 2.0
Lamp Not Included
Product Type Pushbutton Kit
Brand IDEC
Series HW
Actuator Type Extended
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 1NO+1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Amber
Lamp Type Without Lamp
LED Colour Amber
Mechanical Life 5 million Operations
Mode of Operation Momentary
Operational Temperature -25 to 60 deg C
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified
Terminal Type Screw

Description

The IDEC HW1L-M2F11A-K is an Amber Illuminated Pushbutton designed for momentary operation with a round extended profile. It features one Normally Open (NO) and one Normally Closed (NC) contact, capable of handling full voltage applications. The pushbutton's tamperproof construction enhances security, making it suitable for various industrial settings.
