IDECHW1L-M2F11R-K Illuminated Pushbutton Kit 22mm Extended Momentary Red 1NO+1NC

Product Code: HW1L-M2F11R-K

  • Illuminated pushbutton with extended actuator
  • IP65 front protection for robust use
  • 5 million operations mechanical life
  • UL, CE, ULKA, CSA certified for compliance
  • 22 mm diameter with red lamp color
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO+1NC
Insulation Resistance (MO) 100
Operational Temperature Range (°C) -25 to +50
Rated Continuous Current (A) Contact Rating - 10
Pollution Degree 3
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Rated Impulse Withstand Voltage (kV) 2.5
Mounting Hole Diameter (mm) 22
Tightening Torque (Nm) Locking Ring - 2.0
Lamp Not Included
Product Type Pushbutton Kit
Brand IDEC
Series HW
Actuator Type Extended
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 1NO+1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Red
Lamp Type Without Lamp
LED Colour Red
Mechanical Life 5 million Operations
Mode of Operation Momentary
Operational Temperature -25 to 60 deg C
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified
Terminal Type Screw

Description

The IDEC HW1L-M2F11R-K is an illuminated pushbutton designed for intuitive operation with its momentary action and vibrant red color. It features one normally open (NO) and one normally closed (NC) contact, suitable for various control applications. The round, tamperproof design ensures both durability and security, making it a reliable choice for engineering needs.
