IDECYW4L-M2E20QHR Illuminated Pushbutton 22mm Extended Momentary Red 110VAC/DC 2NO

Product Code: YW4L-M2E20QHR

  • Illuminated pushbutton with red LED
  • IP65 front protection for durability
  • Extended actuator for easy operation
  • 5 million operations mechanical life
  • cULus, CE, UKCA, CCC certified
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 30W x 41.4H x 64.8D
Operating Voltage DC (V) 110
Operating Voltage AC (V) 110
No. of Normally-open Contacts 2
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Extended
Bezel Material Metal
Colour Red
Contact Configuration 2NO
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Red
Lamp Type Built-in LED
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model Extended Momentary - With LED Lamp
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Rated Voltage 110 VAC/DC
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW4L-M2E20QHR is an illuminated pushbutton featuring a momentary extended LED with 110V operation. Its design includes space-saving, 10mm thick contact blocks and a removable operator for flexibility. The unit is compact and lightweight, with a durable metal bezel. It also offers unibody pilot lights and key selector switches. The separate contact block simplifies installation and maintenance procedures.
