IDEC YW1P-2EH25G Pilot Light Green 115/120VAC 22mm Dia Mount Hole

Product Code: YW1P-2EH25G

  • Pilot light with momentary actuation
  • 2NO+1NC contact configuration
  • Maintained positions: A, B, C
  • Spring return from A and C to B
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Operating Voltage DC (V) 115/120
Operating Voltage AC (V) 115/120
Dimensions (mm) 29.6W x 24H x 78.8D
Product Type Pilot Light
Brand IDEC
Actuation Type Momentary
Colour Green
Contact Configuration 2NO+1NC
Degree of Protection IP65
Maintained Position A, B, C
Model Dome Transformer - With Incandescent Lamp
Number of Positions 3
Spring Return Position A and C to B

Description

The IDEC YW1P-2EH25G Incandescent Switches are designed for efficiency and ease of use in industrial settings. These switches feature space-saving 10mm thick contact blocks with a removable operator, ensuring a compact and lightweight solution. The durable metal bezel enhances the robustness of unibody pilot lights and key selector switches. Installation and maintenance are simplified thanks to the separate contact block design. Additionally, the pilot lights are equipped with a large lens to provide a broad viewing angle for better visibility.
