Specifications

Dimensions (mm)	4W x 4H x 4D
Suitable For	Isolated Lightning Protection
Weight (kg)	0.962
Accessory Type	Clamp
Clamping Range (mm)	8 - 10
Surface Protection	Untreated
Conductor Diameter (mm)	8
Product Type	MV Clamp
Brand	DEHN
Clamping Range	8-10 mm
Conductor Size	8 mm
Connection Type	Multi-Purpose Connecting Clamp
Connector Type	Multi purpose connecting clamp
Depth	4 mm
Finish	Untreated
Height	4 mm
Lid Screw Type	Hexagon screw
Lightning Current Carrying Capability	100 kA
Material	Stainless Steel
Standards and Approvals	EN 62561-1
Suitable For Use With	Isolated Lightning Protection
Thread Size	M10 x 30 mm
Weight	0.0962 kg
Width	4 mm
