IPD NB72-K 72 Way Neutral Bar 165 A 10 x 20sq-mm 570mm L Bar

Product Code: NB72-K

  • Neutral bar with 165 A rated current
  • M8 bolt size for secure connections
  • Supports 10 x 20 sq-mm cable cross section
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Bar Length (mm) 570
Cross Section (mm²) 10 x 20
Nominal Current (A) 165
Suitable Bolt Size M8
Tunnel Terminal (mm) 6mm for 16mm² conductor
Product Type 72 Way Neutral Bar
Brand IPD
Bolt Size M8
Cable Cross Section 10 x 20 sq-mm
Rated Current 165 A

Description

The Neutral Bar is a 72-way electrical component designed for use with a maximum current of 165A. It has a length of 570mm and a bar size or cross-section of 10mm x 20mm. The Tunnel Terminal has a diameter of 6mm, suitable for use with a 16mm² conductor. The Bolt size required for installation is M8.
