ABB 2CTB803871R1300 Surge Protective Device With Contact Signal 2kA 1-P 20kA 690VAC Plug-In IP20

Product Code: 2CTB803871R1300

  • Surge protector for 690 VAC systems
  • Handles up to 20 kA current
  • Compact DIN rail plug-in design
  • IP20 protection rating
  • Guards against transient overvoltage
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Poles 1
Rated Voltage AC (V) 690
Suitable For To protect the systems against the transient overvoltage (lightning)
Voltage Protection Level - Up (kV) 1.4
Weight (kg) 0.15
Width (mm) 120
Height (mm) 80
Length (mm) 30
No. of Conductors 1
EAN 3660308519610
Product Type Surge Protective Device With Contact Signal
Brand ABB
Connection Type Plug-In
Degree of Protection IP20
Depth 58 mm
Height 95 mm
Lightning Impulse Current 2 kA
Mounting Type DIN Rail
Number of Conductors 1
Number of Poles 1
Rated Current 20 kA
Rated Short Circuit Current 100 kA
Rated Voltage 690 VAC
Suitable For Use With Protect The Systems Against The Transient Overvoltage (Lightning)
Version Plug-in
Voltage Protection Level 1.4 kV
Weight 0.12 kg
Width 17.8 mm

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
