IDECYW4B-M1E21S Non-Illuminated Pushbutton 22mm Flush Momentary Blue 2NO+1NC

Product Code: YW4B-M1E21S

  • Non-illuminated blue flush actuator
  • IP65 front protection rating
  • 5 million operations mechanical life
  • Rated insulation voltage of 600 V
  • cULus, CE, UKCA, CCC certified
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 2
No. of Normally-closed Contacts 1
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Flush
Bezel Material Metal
Button Colour Blue
Colour Blue
Contact Configuration 2NO+1NC
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model Flush - Momentary
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW4B-M1E21S is a compact and efficient pushbutton featuring a flush metal bezel designed for 22mm mounting. Its space-saving design includes 10mm thick contact blocks, while the removable operator ensures flexibility and ease of use. The unit's lightweight construction is complemented by a durable metal bezel, with unibody pilot lights and key selector switches also available. Additionally, the separate contact block simplifies both installation and removal processes.
