Specifications

Dimensions (mm)	214 x 270 x 181
Operational Temperature Range (°C)	-40 to +55
Rated Voltage AC (V)	230
Weight (kg)	2.133
Sound Pressure Level (dBA)	117
Current Consumption (A)	0.16 - 0.36 (For 10J)
Product Type	Flashing Sounder
Brand	PFANNENBERG
Ambient Temperature	-25 to 80 deg C
Contact Configuration	1NO+1NC
Depth	60 mm
Height	46 mm
Housing Colour	Similar to RAL 3000 (Flame Red)
Housing Material	Plastic
Mounting Type	Flange
Shock Resistance	30 g/ms
Standards and Approvals	EN IEC 60947-1, EN IEC 60947-5-1
Width	10 mm
