When selecting a pilot light for industrial or commercial applications, understanding the technical specifications is crucial. This blue illuminated pilot light operates at a rated voltage of 415 VAC and supports both 50 Hz and 60 Hz frequencies, making it versatile for various electrical systems.
The product features an integrated LED lamp, ensuring long-lasting illumination with minimal maintenance requirements. The screw terminal type provides secure connections, while the tightening torque specification of 0.9 N-m ensures optimal stability and performance in demanding environments.
With an IP20 degree of protection, this pilot light is suitable for indoor use where exposure to dust or moisture is limited. Its rear mounting type facilitates easy installation in control panels or machinery.
Connection versatility is another highlight; it accommodates flexible wires with ferrules (both insulated and non-insulated) as well as solid wires ranging from 0.75 to 2.5 square millimeters. Whether you're using single or double wire configurations, this pilot light can handle them all effectively.
The connection type utilizes screw clamps for reliable wire retention, reducing the risk of loose connections over time. Additionally, the recommended wire stripping length is 8 mm—an important detail that ensures proper contact without excess exposed wiring.
This combination of features makes this pilot light an excellent choice for engineers and technicians seeking reliable visual indicators within their electrical systems, balancing robust performance with straightforward installation processes.
