IDEC YW1P-2EM45S Pilot Light Blue 22mm Dia Mount Hole

Product Code: YW1P-2EM45S

  • Compact design: 9.6mm wide, 39.5mm high
  • Operates in -30 to 70°C environments
  • IP20 protection rating
  • Screw terminal for secure connection
  • Rated insulation voltage of 690V
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 29.6W x 24H x 78.8D
Operating Voltage DC (V) 230/240
Operating Voltage AC (V) 230/240
Product Type Pilot Light
Brand IDEC
Ambient Temperature -30 to 70 deg C
Colour Brown
Connecting Capacity 1/2 x 0.75-2.5 sq-mm Flexible with Ferrule, 1/2 x 0.75-2.5 sq-mm Flexible with Insulated Ferrule, 1/2 x 0.75-2.5 sq-mm Flexible, 1/2 x 0.75-2.5 sq-mm Solid
Contact Configuration 1NO
Degree of Pollution IP3
Degree of Protection IP20
Depth 27.7 mm
Height 39.5 mm
Model Dome Transformer - With Incandescent Lamp
Mounting Type Front
Operational Temperature -30 to 70 deg C
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 4 kV
Rated Insulation Voltage 690 V
Storage Temperature -40 to 70 deg C
Terminal Type Screw
Tightening Torque 0.9 N-m
Width 9.6 mm
Wire Stripping Length 10 mm

Description

The IDEC YW1P-2EM45S is a transformer type incandescent pilot light designed for efficient space utilization with its slim 10mm contact blocks. This compact and lightweight unit features a durable metal bezel and offers easy installation and removal due to its separate contact block design. The large lens of the pilot light ensures visibility from a wide angle, making it suitable for various industrial applications.
