IDEC YW1P-2EH5W Pilot Light White 22mm Dia Mount Hole

Product Code: YW1P-2EH5W

  • Compact design: 32 x 32.5 x 64.5 mm
  • Wide temp range: -30 to 70°C
  • Durable metal housing
  • Compliant with IEC/EN & UL standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 29.6W x 24H x 78.8D
Operating Voltage DC (V) 100/110
Operating Voltage AC (V) 100/110
Product Type Pilot Light
Brand IDEC
Colour White
Degree of Protection IP65
Depth 64.5 mm
Height 32.5 mm
Housing Material Metal
Model Dome Transformer - With Incandescent Lamp
Operational Temperature -30 to 70 deg C
Standards and Approvals IEC/EN 60947-1, IEC/EN 60947-5-1, UL 508
Storage Temperature -40 to 70 deg C
Suitable For Use With Standard Pushbuttons/Switches
Weight 0.039 kg
Width 32 mm

Description

The IDEC YW1P-2EH5W is a transformer type incandescent pilot light designed for 100/110V AC systems. This compact and lightweight unit features a space-saving design with 10mm thick contact blocks and a removable operator for ease of use. The metal bezel enhances durability, while the unibody construction ensures consistency across pilot lights and key selector switches. Installation and maintenance are simplified thanks to the separate contact block, and the large lens offers an expansive viewing angle for clear visibility.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
