IDEC YW1P-2UQM3A Pilot Light With LED Amber 230/240VAC 22mm Dia Mount Hole

Product Code: YW1P-2UQM3A

  • 24 VDC rated voltage
  • Operates from -20 to 55°C
  • IP65 protection rating
  • Fits 22 mm mounting holes
  • Green LED lamp
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Insulation Resistance (MO) 100
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC (V) 230/240
Product Type Pilot Light With LED
Brand IDEC
Series YW
Degree of Protection IP65
Insulation Resistance 100 MOhm
Lamp Colour Green
Lamp Type LED
LED Colour Amber
Mounting Hole Diameter 22 mm
Operational Temperature -20 to 55 deg C
Rated Voltage 24 VDC
Terminal Type Screw (M3.5)

Description

The IDEC YW1P-2UQM3A Unibody Pilot Light is a robust and efficient indicator designed for clear signaling. It features an LED Amber light for high visibility and operates on 230/240VAC. This pilot light's 22mm dome design ensures straightforward installation. Safety is enhanced with IP20 finger safe terminals, making it suitable for various engineering applications.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
