IDEC YW1P-2EM42S Pilot Light With LED Blue 22mm Dia Mount Hole

Product Code: YW1P-2EM42S

  • Operates at 50/60 Hz frequency
  • Compact size: 9.6mm x 39.5mm x 27.7mm
  • Wide temp range: -30 to 70°C
  • IP20 protection rating
  • Screw clamp connections
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Insulation Resistance (MO) 100
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC (V) 230/240
Lamp Included
Product Type Pilot Light With LED
Brand IDEC
Series YW
Ambient Temperature -30 to 70 deg C
Colour Brown
Connecting Capacity 1/2 x 0.75-2.5 sq-mm Flexible with Ferrule, 1/2 x 0.75-2.5 sq-mm Flexible with Insulated Ferrule, 1/2 x 0.75-2.5 sq-mm Flexible, 1/2 x 0.75-2.5 sq-mm Solid
Connection Type Screw Clamp
Contact Configuration 1NC
Degree of Pollution IP3
Degree of Protection IP20
Depth 27.7 mm
Height 39.5 mm
Lamp Type Included
Model Transformer Type
Mounting Type Front
Operational Temperature -30 to 70 deg C
Rated Frequency 50/60 Hz
Storage Temperature -40 to 70 deg C
Terminal Type Screw (M3.5)
Tightening Torque 0.9 N-m
Width 9.6 mm
Wire Stripping Length 10 mm

Description

The IDEC YW1P-2EM42S is a dome-shaped Pilot Light with a blue LED and an integrated transformer, designed for 22mm mounting. It operates at 230/240VAC, ensuring low heat production and longevity. The unit's terminals are IP20 finger safe to enhance operational safety.
