IDEC YW1P-2EQHPW Dome Pilot Light with Built-In LED Pure White 110VDC 22mm Dia Mount Hole

Product Code: YW1P-2EQHPW

  • Illuminated pilot light with yellow LED
  • Operates at 120 VAC, 50/60 Hz
  • Compact size: 9.8 mm width, 39.5 mm height
  • Screw terminal for secure connection
  • Front mounting design with IP20 protection
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 29.6W x 24H x 61.7D
Operating Voltage DC (V) 110
Operating Voltage AC (V) 110
Product Type Dome Pilot Light
Brand IDEC
Colour Light Yellow
Connecting Capacity 0.75-2.5 sq-mm
Connection Type Screw Clamp
Degree of Pollution IP3
Degree of Protection IP20
Depth 56 mm
Height 39.5 mm
Illumination Illuminated
Lamp Type Built-In LED
LED Colour Yellow
Model Dome Full Voltage - LED Lamp
Mounting Type Front
Operational Temperature -30 to 70 deg C
Rated Frequency 50/60 Hz
Rated Voltage 120 VAC
Storage Temperature -40 to 70 deg C
Terminal Type Screw
Tightening Torque 0.9 N-m
Weight 0.018 kg
Width 9.8 mm
Wire Stripping Length 8 mm

Description

The IDEC YW1P-2EQHPW is a compact, full voltage pilot light featuring a pure white LED and a 22mm green dome. Its space-efficient design includes a 10mm thick contact block and a removable operator for straightforward installation or maintenance. The metal bezel enhances durability, while the unibody construction ensures consistent performance. A large lens offers an expansive viewing angle, making it easy to monitor from various positions. This pilot light is part of the GREENYW series, known for its lightweight and easy-to-install components.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
