IDEC YW1P-2UQ4R Pilot Light With LED Red 24VDC 29.8 mm Dia Mount Hole

Product Code: YW1P-2UQ4R

  • Operates at 110 VDC for efficient power use
  • Functions in temps from -20 to 55°C
  • IP65 rating ensures dust and water resistance
  • Fits standard 22 mm mounting holes
  • Bright white LED for clear visibility
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Insulation Resistance (MO) 100
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC/DC (V) 24
Product Type Pilot Light With LED
Brand IDEC
Series YW
Degree of Protection IP65
Insulation Resistance 100 MOhm
Lamp Colour White
Lamp Type LED
LED Colour Red
Mounting Hole Diameter 22 mm
Operational Temperature -20 to 55 deg C
Rated Voltage 110 VDC
Terminal Type Screw (M3.5)

Description

The IDEC YW1P-2UQ4R Unibody Pilot Light is a versatile and efficient indicator designed for clear signaling with its vibrant red LED. Compatible with both 24VAC and 24VDC power sources, it offers installation flexibility. The unit's 22mm size allows for straightforward integration into control panels or machinery. Safety is prioritized with IP20 finger safe terminals, ensuring secure operation in various engineering applications.
