IDEC YW1P-2EH2PW Pilot Light With LED Pure White 22mm Dia Mount Hole

Product Code: YW1P-2EH2PW

  • Non-illuminated black pilot light
  • Operates in -25 to 70°C range
  • IP66 protection rating
  • Screw clamp connection
  • Black plastic bezel
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Insulation Resistance (MO) 100
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC (V) 100/110
Lamp Included
Product Type Pilot Light With LED
Brand IDEC
Series YW
Actuator Type Knob
Bezel Type Black Plastic
Colour Black
Connection Type Screw Clamp
Degree of Protection IP66
Illumination Non-Illuminated
Lamp Type Included
Model Transformer Type
Operational Temperature -25 to 70 deg C
Power Loss 2 W
Resistance 10 kOhm
Storage Temperature -40 to 85 deg C
Terminal Type Screw (M3.5)

Description

The IDEC YW1P-2EH2PW is a dome-type Pilot Light with an integrated LED transformer, emitting a pure white light. Designed for 100/110VAC systems, it ensures compatibility with standard voltages and features a convenient 22mm mounting size. The LED technology provides low heat emission and longevity, while the IP20 finger safe terminals enhance user safety during operation.
