Specifications

LED Block Rated Voltage	12 VAC/DC
Bezel Material	Metal
Product Type	Pilot Light Kit
Brand	ABB
Colour	Blue
Connecting Capacity	Flexible with Ferrule 1 x 0.75...2.5 sq-mm, Flexible with Ferrule 2 x 0.75...2.5 sq-mm, Flexible with Insulated Ferrule 1 x 0.75...2.5 sq-mm, Flexible with Insulated Ferrule 2 x 0.75...2.5 sq-mm, Flexible 1 x 0.75 ... 2.5 sq-mm, Flexible 2 x 0.75 ... 2.5 sq-mm, Solid 1 x 0.75...2.5 sq-mm, Solid 2 x 0.75...2.5 sq-mm
Connection Type	Screw Clamp
Degree of Protection	IP20
Illumination	Illuminated
Lamp Type	Integrated LED
Light Blocks Type	Power Supply
Mounting Type	Rear
Rated Frequency	50/60 Hz
Rated Voltage	110-130 VAC
Terminal Type	Screw
Tightening Torque	0.9 N-m
Wire Stripping Length	8 mm
