IDEC YW1P-2EQ7G Dome Pilot Light with Built-In LED Green 24VDC 22mm Dia Mount Hole

Product Code: YW1P-2EQ7G

  • Compact design: 9.8 mm width
  • Front mounting for easy installation
  • Operates in -30 to 70°C temp range
  • Built-in LED illumination, red color
  • Screw clamp connection for secure fit
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 29.6W x 24H x 61.7D
Operating Voltage DC (V) 24
Operating Voltage AC (V) 24
Product Type Dome Pilot Light
Brand IDEC
Colour Red
Connecting Capacity 0.75-2.5 sq-mm
Connection Type Screw Clamp
Degree of Pollution IP3
Degree of Protection IP20
Depth 56 mm
Height 39.5 mm
Illumination Illuminated
Lamp Type Built-In LED
LED Colour Red
Model Dome Full Voltage - Incandescent Lamp
Mounting Type Front
Operational Temperature -30 to 70 deg C
Rated Frequency 50/60 Hz
Rated Voltage 24 VAC
Storage Temperature -40 to 70 deg C
Terminal Type Screw
Tightening Torque 0.9 N-m
Weight 0.02 kg
Width 9.8 mm
Wire Stripping Length 8 mm

Description

The IDEC YW1P-2EQ7G is a compact and efficient pilot light, featuring a 10mm thick contact block for space-saving installation. Its design includes a metal bezel and a unibody construction, ensuring durability and ease of use with removable operators. The separate contact block simplifies the installation and maintenance process. Additionally, the pilot light is designed with a large lens to provide an expansive viewing angle, suitable for various industrial applications.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
