IDEC RH2B-UAC6 Power Relay DPDT 6VAC Coil 10A Blade Terminal

Product Code: RH2B-UAC6

  • 6 VAC, 10 A rated for reliable power handling
  • DPDT contact config with silver cadmium oxide
  • Fast 20 ms operating time
  • CE, CSA, RoHS approved for compliance
  • Operates in -25 to 40°C range
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Coil Voltage AC (V) 6
Insulation Resistance (MO) 100
No. of Poles 2P
Operational Temperature Range (°C) -25 to +40
Rated Current (A) 10
Weight (g) 37
Operating Humidity 45 to 85% RH (no condensation)
Product Type Power Relay
Brand IDEC
Series RH
Contact Configuration DPDT
Contact Material Silver Cadmium Oxide
Humidity 45-85%
Insulation Resistance 100 MOhm
Operating Time 20 ms
Operational Temperature -25 to 40 deg C
Rated Current 10 A
Rated Voltage 6 VAC
Relay Type RH2 2PDT Relay
Standards and Approvals CE, CSA, RoHS
Terminal Type Blade
Weight 37 g

Description

The IDEC RH2B-UAC6 is a compact power relay from the RH2 Series, designed for efficient switching with a DPDT configuration and a 6VAC coil voltage. It offers a substantial 10A contact capacity within its space-saving design. The relay features 2-pole blade style terminals for secure connections, making it suitable for various applications where size and power are considerations.
