IDEC RY2S-UAC6 Miniature Relay DPDT 3A

Product Code: RY2S-UAC6

  • Compact miniature design
  • Rated current of 3 A
  • DPDT gold plated silver contacts
  • High electrical life: 200,000 ops
  • CE, cRuus, and CSA approved
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts DPDT
Coil Voltage AC (V) 6
Insulation Resistance (MO) 100
Operational Temperature Range (°C) -25 to 50
Weight (g) 23
Minimum Mechanical Life 5,000,000
Minimum Electrical Life 200,000
Resistance to Vibrations 10 to 55Hz
Resistance to Shock (m/s²) 100
Contact Resistance (mO) 50
Product Type Miniature Relay
Brand IDEC
Coil Voltage 6 VAC
Contact Configuration DPDT
Contact Material Gold Plated Silver
Contact Resistance 50 MOhm
Electrical Life 200000 Operations
Humidity 45-85%
Insulation Resistance 100 MOhm
Mechanical Life 5000000 Operations
Model Basic
Operational Temperature -25 to 55 deg C
Rated Current 3 A
Shock Resistance 100 ms
Standards and Approvals CE, cRuus, CSA
Vibration Resistance 10-55 Hz
Weight 23 g

Description

The IDEC RY2S-UAC6 is a versatile DPDT relay designed for reliable switching operations in various applications. It features gold-plated contacts for enhanced conductivity and durability. The relay offers flexible installation options with blade plug-in or PCB terminals, and additional features such as an indicator light, check button, and top mounting bracket are available. It can be mounted using a top mount, DIN socket, PCB socket, or panel mount socket to suit different setup requirements.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
