IDEC RY2S-ULAC50V Miniature Relay DPDT 3A

Product Code: RY2S-ULAC50V

  • Compact miniature design for versatile applications
  • Durable gold-plated silver contacts
  • Long electrical life: 200,000 operations
  • High insulation resistance of 100 MOhm
  • CE, cRuus, and CSA certified
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts DPDT
Coil Voltage AC (V) 50
Insulation Resistance (MO) 100
Operational Temperature Range (°C) -25 to 50
Weight (g) 23
Minimum Mechanical Life 5,000,000
Minimum Electrical Life 200,000
Resistance to Vibrations 10 to 55Hz
Resistance to Shock (m/s²) 100
Contact Resistance (mO) 50
Product Type Miniature Relay
Brand IDEC
Coil Voltage 50 VAC
Contact Configuration DPDT
Contact Material Gold Plated Silver
Contact Resistance 50 MOhm
Electrical Life 200000 Operations
Humidity 45-85%
Insulation Resistance 100 MOhm
Mechanical Life 5000000 Operations
Model With Indicator
Operational Temperature -25 to 55 deg C
Rated Current 3 A
Shock Resistance 100 ms
Standards and Approvals CE, cRuus, CSA
Vibration Resistance 10-55 Hz
Weight 23 g

Description

The IDEC RY2S-ULAC50V is a versatile DPDT relay designed for reliable performance in various applications. It features gold-plated contacts for enhanced conductivity and durability. This relay offers flexible installation options, including blade plug-in or PCB terminals, and can be mounted using top mounting, DIN socket, PCB socket, or panel mount socket. Additional features include an optional indicator light, check button, and top mounting bracket for easy operation and monitoring.
