Specifications

Cable Length (m)	2
Pollution Degree	3
Rated Insulation Voltage (V)	32DC
Rated Impulse Withstand Voltage (kV)	0.8
Maximum Ambient Temperature (°C)	60
Maximum Reaction Time (ms)	100
Minimum Ambient Temperature (°C)	-25
Termination	Connecting Cable, 2-Pole
Wire Cross Section (mm²)	0.23mm² (Diameter)
Sensor Length (mm)	13
Sensor Height (mm)	26
Door Hinge Position	Right
Resistance to Shock (g/ms)	30g / 11ms
Direction of Motion	Head-on to the Active Surface
Recommended Actuator	BPS 260-1
Resistance to Vibrations	10 ... 55Hz, Amplitude 1mm
Maximum Storage Temperature (°C)	70
Minimum Storage Temperature (°C)	-25
Product Type	Magnetic Safety Sensor
Brand	SCHMERSAL
Action	Magnetic Drive
Actuating Element	Magnet
Cable Length	2 m
Degree of Protection	IP67
Housing Material	Glass Fibre Reinforced Thermoplastic
Installation Conditions	Quasi-flush
Mounting Type	Quasi-Flush
Number of Poles	2
Operating Cycles	500000
Operational Temperature	-25 to 60 deg C
Overvoltage Category	3
Performance Level	e
Rated Current	50 mA
Rated Insulation Voltage	32 VDC
Rated Voltage	18-31.6 VDC
Sensor Size	13 mm L x 26 mm H
Standards and Approvals	EN IEC 62026-2 EN ISO 13849-1 EN IEC 60947-5-3 EN IEC 61508
Vibration Resistance	10-55 Hz
Wire Size	0.23 sq-mm
