Specifications

Maximum Cable Cross Section (mm²)	1 x 2.5
Rated Insulation Voltage (V)	250
Rated Impulse Withstand Voltage (kV)	6
Enclosure Material	Metal, zinc die-cast
Utilisation Category	DC-13 \| AC-15
No. of Safety Contacts	2
Minimum Ambient Temperature (°C)	-20
Standards	EN IEC 60947-5-1 / EN IEC 60204-1 / EN IEC 60947-5-3 / EN IEC 62061 / EN IEC 60947-5-5 / EN IEC 60947-1 / EN 81-20/-50
Sensor Length (mm)	33
Switching Principle	Slow action
EAN	4030660000000
eCl@ss Number, Version 9.0	27-27-27-04
Sensor Height (mm)	173.5
Rated Short-circuit Current (A)	100
ETIM 7.0	EC002549
ETIM 6.0	EC002549
eCl@ss Number, Version 11.0	27-27-27-04
Minimum Mechanical Life	20000000 Operations
Gross Weight (g)	405.05
Utilisation Category DC-13	24 VDC
Net Weight (g)	85
Maximum Fuse Rating	6 A gG D-fuse
Switching Element	2 NO contacts / 2 NO contacts
Maximum Ambient Temperature (°C)	50
Minimum Cable Cross Section (mm²)	0.75
Maximum Actuating Speed (m/s)	2
Product Type	Magnetic Safety Sensor
Brand	SCHMERSAL
Actuating Element	Magnet
Actuator Type	Roller lever
Cable Length	3 m
Contact Configuration	1NO+1NC
Contact Material	Silver
Degree of Protection	IP67
Housing Material	Glass Fibre Reinforced Thermoplastic
Mounting Type	Quasi-Flush
Operational Temperature	-25 to 70 deg C
Rated Current	0.01 A
Rated Frequency	5 Hz
Rated Power	0.24 W
Sensor Size	44 mm L
Shock Resistance	30 g/ms
Standards and Approvals	BG-GS-ET-14; EN IEC 60947-5-3; EN ISO 13849-1
Terminal Type	Connector M12, 4-pole
Vibration Resistance	10-55 Hz
Wire Size	0.25 sq-mm
