Schmersal 101193763 Magnetic Reed Switch 3A BP 10 Screw Terminal

Product Code: 101193763

  • Rated for 250 VAC and 3 A
  • Durable die-cast light alloy housing
  • IP67 protection against dust and water
  • Operates in -25 to 70°C temperature range
  • Long mechanical life of 1 billion operations
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Maximum Temperature (°C) 80
Minimum Temperature (°C) -40
Rated Minimum Operational Voltage DC (V) 22
Rated Maximum Operational Voltage DC (V) 49
Product Type Magnetic Reed Switch
Brand SCHMERSAL
Series NT24K
Accuracy 0.3 mm
Actuating Element Magnet
Actuating Speed 18 m/s
Bounce Duration 0.3 ms
Control Element Reed Contacts
Degree of Protection IP67
Housing Material Die Cast Light Alloy, Painted
Mechanical Life 1000000000 Operations
Operational Temperature -25 to 70 deg C
Rated Current 3 A
Rated Voltage 250 VAC
Resistance 10-55 Hz
Standards and Approvals EN IEC 60079-0, EN IEC 60079-15, EN 60079-31
Switching Capacity 120 W
Switching Type Magnetic Drive

Description

Maximize your network's efficiency with the Schmersal NT24K Series 14-Port Gigabit Managed POE+ Industrial Ethernet Switch. Engineered for hazardous environments, this robust switch features eight RJ-45 ports and six ST or SC duplex fiber ports to ensure a wide range of connectivity options. With support for singlemode fiber and a substantial 15km fiber length, it offers extensive reach for complex industrial setups. The switch operates on a power input range of 22-49 VDC and can handle a maximum input current of 11.24 A at 24 VDC, making it both powerful and adaptable. Designed specifically for challenging conditions, this magnetic reed switch is an ideal solution for maintaining seamless network performance in critical industrial applications.
